Zeus DC Split — 800–1200kW
Centralized power cabinet feeding up to 12 dispensers — the backbone for full-scale superstation builds with dynamic load balancing.
480kW
Max Output
600A
Liquid-Cooled
96%
Peak Efficiency
2
Connectors
7 power configurations available — 300 / 320 / 330 / 360 / 400 / 440 / 480kW. CCS1, NACS & CHAdeMO combinations, air or liquid cooling.
Why Station Owners Choose Pro Max
A
High Current Output
Liquid cooling delivers up to 600A; air-cooled units reach 400A — no charge-rate drop-off.
%
96%+ Peak Efficiency
More of every kilowatt reaches the battery, lowering operating cost per session.
V
Wide Voltage Range
150–1000 VDC output covers the vast majority of EVs on the road today.
⛨
Type 3R & IK10 Rated
Built for outdoor duty with C4 anti-corrosion protection and vandal-resistant housing.
Technical Specifications
| AC Input Voltage | 3-phase 480 VAC ±10%, 50/60 Hz, 3P+PE |
| Output Voltage Range | 150–1000 VDC |
| Max Output Current (connector) | 300A / 350A / 400A optional (air cooling); 500A / 600A optional (liquid cooling) |
| Number of Outputs | 2 — any two combinations of CCS1, NACS, CHAdeMO |
| Peak Efficiency | ≥96% |
| Power Factor | ≥0.99 |
| Dimensions (W×D×H) | 850mm × 800mm × 2050mm (2120mm with cable management) |
| Weight | ≤1,763.7 lb |
| Cooling | Air cooling / Liquid cooling |
| IP & IK Rating | Type 3R & IK10 (HMI IK8) |
| Operating Temperature | −22°F to 131°F (derating above 131°F) |
| Noise Level | <70dB @ 3m, full power |
| Display | 10.1″ touch screen |
| User Authentication | RFID, QR code, Application (POS Machine optional) |
| Network Connection | Ethernet, WiFi (4G optional) |
| Communication Protocol | OCPP 1.6J, upgradeable to OCPP 2.0.1 |
Available Power Configurations
| Model | Max Output | Connector | Max Current |
|---|---|---|---|
| TS-ULDC1-300F-DUU | 300kW | Any 2 of CCS1 / NACS / CHAdeMO | 300–600A |
| TS-ULDC1-360F-DUU | 360kW | Any 2 of CCS1 / NACS / CHAdeMO | 300–600A |
| TS-ULDC1-400F-DUU | 400kW | Any 2 of CCS1 / NACS / CHAdeMO | 300–600A |
| TS-ULDC1-480F-DUU | 480kW | Any 2 of CCS1 / NACS / CHAdeMO | 300–600A |
Certifications & Standards
ETL
FCC
IC
Energy Star
UL 2202
UL 2231-1 / 2231-2
ISO 15118
DIN 70121
FCC
IC
Energy Star
UL 2202
UL 2231-1 / 2231-2
ISO 15118
DIN 70121
Ready to spec a Pro Max station?
Our team will help you choose power, connector mix, and cooling for your site.
